Modern Elevator Spare Part AMD Lift Door Opening Rope Pulley Elevator Door Hanger Roller Hall

Modern Elevator Spare Part AMD Lift Door Opening Rope Pulley Elevator Door Hanger Roller Hall

Modern elevator spare part

AMD elevator spare part

AMD lift spare part

Place of Origin:

Zhejiang, China

Brand Name:

Boguan

Model Number:

AMD

Chat Now
Request A Quote
Product Details
Warranty:
1 Year
Material:
Metal
After-sale Service:
Online Technical Support
Project Solution Capability:
Total Solution For Projects
Application:
Elevator Door
Design Style:
Modern
Highlight:

Modern elevator spare part

,

AMD elevator spare part

,

AMD lift spare part

Payment & Shipping Terms
Minimum Order Quantity
2 pieces
Price
$5-7/ piece
Product Description

Modern Elevator Spare Part AMD Lift Door Opening Rope Pulley Elevator Door Hanger Roller Hall Door Hanging Wheel ADM Rope Wheel Door Pulley







Elevator Door Hanger Roller Detailed Description

Elevator door hanger roller is an essential spare part for elevator car doors and landing doors, mounted on the door hanger plate and rolling along the top header guide rail. It consists of outer rolling rim, sealed deep groove ball bearing, metal hub and mounting bolt, with standard specs marked as Diameter×Thickness×Bearing Model.

Available in PU polyurethane, nylon, solid steel and rubber materials for different applications: PU rollers for high-frequency passenger elevators with low noise and rail protection; nylon rollers for dusty freight elevators; steel rollers for heavy-duty cargo lifts.

Main Functions

1. Bear the full weight of elevator door panels;
2. Guide linear door movement and prevent derailment;
3. Reduce friction and running noise via bearing rolling design;
4. Buffer impact and improve door system safety.

Adopts double-side sealed bearings with pre-greased lubrication, dustproof and maintenance-free. Compatible with Otis, Kone, Fermator and other mainstream elevator brands for direct replacement, stable operation within -20℃~+60℃ shaft environment.







Welcome to visit, if you didn't find the goods you want can send processing drawing to us with production.



1, Many specifications

2, good quality

3, reasonable prices

4, thoughtful service

Main products: complete elevators, various specifications of rope fastening, oil buffer, guide shoe, shoe lining, overspeed governor, safety accessories and all elevator parts.
